Use the Video Enhanced Adapter, and choose from the terminals be-

low to connect.

3.2 Turning on/off the projector

1. Power cord

2. VGA signal input terminal

3. USB mouse control

4. S-Video signal input terminal

5.6 Composite Video signal input

terminals

7. PC Audio In/Out terminals

Notes Connecting to a computer

1. Make sure that both projector and computer are turned

off.

2. Plug the USB cable into the computer.

3. Plug one end of the VGA cable into the projector.

4. Plug the other end into the computer.

5. Plug the power cord into the power connector on the

side of the projector,and plug the other end into an outlet.

6. Turn on the projector first, then turn on the computer.

ＭＸ３　ｍａｎｕａｌ．ｐ６５ 02-12-17, 16:398
